Description
- Colour Corrected Infinity Optical System (CCIS®)
- Binocular head, siedentopf type with built-in digital camera
- Sensor type: CMOS
- Sensor size: 1/2.5″
- Capture resolution: 5MP (2592×1944 pixels)
- Live display mode through Wi-Fi: 1920×1080 (Full HD)
- Live display mode through ethernet: 1280×720, 1920×1080 pixels (Full HD)
- Live display mode through HDMI: 1920×1080 (Full HD)
- Epi-illuminator LED with rotatable analyzer 360º, Bertrand lens, fixed polarizer and slot for compensators
- Widefield UC-WF10X/20mm, +/- 4 diopter on both eyepieces
- Nosepiece: Reversed quintuple, coded with single centering holes
- Objective classification: CCIS® UC Plan Achromatic (strain-free), DIN
- Objectives: 5X/0.13 (WD 17.3mm), 10X/0.25 (WD 16.3mm), 20X/0.40 (WD 7.3mm), UC 40X/0.65/S (WD 0.6mm)
- Stage: Circular rotating 360º, lockable
- Stage size: Ø160mm
- Focusable and centerable Achromat Swing-out Abbe condenser N.A. 0.90/0.13 (strain-free) and rotatable polarizer
- Coaxial coarse and fine focusing system with tension adjustment
- Incident illumination: LED 3W smart segmental ringlight with integrated field and aperture diaphragms
- Transmitted illumination: Koehler LED 3W & Quartz halogen 6V/30W with intensity control
- Illumination interchangeability: Halogen/LED and LED color temperature interchangeability
- Illumination features Motic Light Tracer: Light memory, sleep mode (auto on-off), nosepiece LED light intensity and mode indicator
- Accessories included Dust cover, power cord, Allen key, blue filter, halogen bulb, LED module, adjustable key for nosepiece, interference color chart, screws for metal extension support, HDMI Cable, Wi-Fi USB dongle, calibrations
